ATV towable tow behind 15hp gasoline petrol disc wood branch chipper shredder leaf mulcher
Heavy-Duty Electric-Start Wood Chipper
The GS150 is an extremely powerful wood chipper from Hyundai, able to handle even the most established of
tree branches with diameters up to a massive 12cm.
Powerful Loncin Engine
Powered by a heavy-duty 420cc / 15hp 4-stroke OHV electric-start Loncin engine, it will provide you with a powerful
performance each and every time. Featuring an electric-start function, this ensures that you can get chipping at the
push of a button with no effort required, unlike previous recoil pull-start chipper models.
Heavy-Duty Electric-Start Wood Chipper
The GS150 is an extremely powerful wood chipper from Hyundai, able to handle even the most established of tree
branches with diameters up to a massive 12cm.
Specifications
| Model | GS150 |
| Start Method | Electric or Recoil |
| Drive Type | Belt Drive |
| Chipping Capacity (mm) | 120 |
| Feed Hopper Opening Size (mm) | 500x460 |
| Infeed Throat Opening Size (mm) | 160x176 |
| Disc Size (mm) (Diameter / Thickness) | 550 x 20 |
| Knives | 2 |
| Features | ATV Towing Bar, 360° Rotating Chute |
| Handle Type | N/A |
| Safety Features | Stop Button |
| Engine Model | Loncin 420FD or B&S XR2100 |
| Engine Type | 4 Stroke OHV Single Cylinder |
| Engine Size (cc) | 420 |
| Rated Power (hp) | 15 |
| Disc Speed (RPM) | 2200 |
| Fuel | Petrol |
| Fuel Capacity (L) | 6.5 |
| Engine Oil | SAE30 |
| Engine Oil Capacity (ml) | 1100 |
| Gross Weight (kg) | 270 |
| Tyres | 5.7-8 |
| Off Road Tow Bar | Yes |
| Fully Assembled Dimensions (H x W x L) (mm) | 2550 x 1010 x 1810 |
| Package Dimensions (H x W x L) (mm) | 1250 x 770 x 1050 |
| Fuel Type / Power Source | Petrol |
| Product Type | Wood Chipper |
| Warranty (years) | 1 |
| Commercial Warranty (years) | 1 |
| In The Box | Petrol Wood Chipper, Tool Set, Manual |
There is an Emergency stop Bar at the feeder hopper.
When it is depressed it cuts off the engine.
As the engine reduces speed the clutch will release and the Disc will begin to slow down.
Easy access inside the disc cover to the disc and blades via a quick release latch.
The disc cover has a micro switch to stop the engine being started with the cover open.
The exit shoot, can swivel 360°, throwing the chip into a nearby trailer or pile.
LONCIN 420cc 27Nm
Easy Pull Start
Double Belt with Clutch (no load during starting)
Capacity 4” 100mm - cutting point is 160Wx 200H (mm)
360° Rotating Discharge Chute
Double Blades (reversible)
Anvil: Adjustable
Large feed shoot, with gravity self feed.
LED tail light and NZ & pin plug
Tyres: E-Mark 5.7-8 Road Tyre
Folding height adjustable jockey wheel
Coupling 1 7/8”
Extremely strong and robust. Main housing is made of 5mm steel plate, and the base of 4mm plate.
10mm bearing boss plate.
Weight: 260kgs
